CT-klem split core diameter 10
Standards：IEC/EN61869-1, IEC/EN61869-2
Ratio：60A/20mA
Class：0.5
Turns：1
Accepted wire diameter：10mm
Rated frequency: 50/60Hz
Continuous overload: 120%In
Protection level: IP30
Security factor: FS＜5
Maximum system voltage: 720V AC
Test voltage: 3kV AC(1min)
Rated short-time thermal current: Ith=40~60In
Rated dynamic current: Idyn=2.5Ith
Casing: Non-flammable, polycarbonate self-extinguishing ABS
